Control Lights, TVs, Motors, Fans, Cameras, Video signals, Audio signals, electrically operated Doors/ Locks/ Windows/ Blinds/ Cars or Other Appliances.
You can turn on/off the receiver with transmitter (remote control) from any place within a reliable distance; the wireless signal can pass through walls, floors and doors.
Reliable control: The transmitter (Encoding) and the receiver (Decoding) use an 8-bit code.
One/several transmitters can control one/several receivers simultaneously.
If you use two or more receivers in the same place, you can set them with different codes.
Transmitting Frequency: 315MHz / 433MHz.
Model No.: S2M-AC110 / S2M-AC220
Channel: 2 CH
Control Mode: Momentary (Press and hold -> On; Release -> Off)
Coding Type: Fixed code
Coding Setting: By soldering
Power Supply (Operating Voltage): AC100~120V (S2M-AC110), AC200~240V (S2M-AC220)
PCB size: 80mm x 35mm x 14mm
Case size: 100mm x 40mm x 24mm
Maximum Working Current: 4A / each channel
Model No.: C-2
Channel: 2 CH
Remote Control Distance: 100m / 300ft (theoretically)
Encode: Fixed code by soldering
Unit size: 58mm x 39mm x 16mm
Power Supply: 1 x 23A -12V battery (included, can be used for 12 months)
Press button 1 and hold: Turn on relay 1, terminals 3 and 4 output AC power.
Release button 1: Turn off relay 1, terminals 3 and 4 no output.
Press button 2 and hold: Turn on relay 2, terminals 3 and 5 output AC power.
Release button 2: Turn off relay 2, terminals 3 and 5 no output.
1 x Receiver: S2M-AC110 / S2M-AC220 (2 Channels / Momentary Control Mode)
2 x Transmitter: C-2
1 x User manual
The distance of 100m is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be exposed to some interference by other signals. Therefore, the actual distance could not reach 100m. If you need longer range, you can choose other series of remote control, such as CB Serie (1000m/3000ft) - Click here to link to; Or you can add the External Extend Antenna (model:0020909 ) on the receiver for improve the range - Click here to link to.
