500M 1 Button Wall Mounting Wireless Remote Transmitter

Price: US $23.00

Model: 0021202

Please Choose:

Qty:

Product Description:

Model No.: 0021202
Wall Mounting
Shell Color: White
Channel/Button: 1
Button Symbol: no symbol
Operating Voltage: 6V(1×6F22 9V battery )
Operating Current: 30-50mA
Operating Frequency: 433.92Mhz
Encoding Chip: EV1527
Encoding Type: Learning code (up to 1 million codes, reducing code collision and unauthorized code scanning possibilities.)
Transmitting Distance: 500m / 1500ft (theoretically)
The distance of 500m is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be exposed to some interference by other signals. Therefore, the actual distance may or may not reach 500m.
Modulation Mode: ASK
Operating Temperature: -20 ° C to +70 ° C
Unit Size: 86mm x 86mm x 37mm
Weight: 120g
Case Material: Plastic
This transmitter can work with different kinds of receivers, include model 0020043 (S1U-DC12), 0020330 (S1U-AC220), 0020046 (S1PU-DC12), 0020275 (S1PU-AC220), 0020610 (S1RU-DC12), etc.
Uses: garage doors, lights, motorcycles, car alarm products, home security products, wireless remote control products, industrial control products.

Usage:

Install Wall Mounting Remote to wall.
When you press button, the receiver is activated, and the connected device is turned on.
When you press button again, the receiver is deactivated, and the connected device is turned off.

Package Include:

1× Wall Mounting Remote
1× 6F22 9V Batteriy

Please Note:

1. The remote control and receiver will only work together if they have identical parameters, such as wireless frequency, encoding type, oscillation resistance, and operating channel.

2. Different remote controls are compatible with different receivers. If customers order only our remote controls, please confirm with us before placing the order to ensure they are compatible with the customer's receiver.

3. If customers order our remote controls separately without first confirming with us and subsequently discovers upon receipt that it is incompatible with their receiver, we will not assume any liability and will not accept returns or refunds.
