Remote control calling system is the hi-tech electronic product which is integrated wireless communication and computer technology. It includes calling button and calling receiver. Each system has one calling receiver and many calling buttons. When there is a calling from a calling button, calling receiver will display corresponding number.
It is widely applied to restaurants, coffee shops, karaoke rooms, discos, sauna rooms, beer houses, pubs, night clubs, bowling alleys, golf courses, video halls, hotels, hospitals, schools, chain stores ,shops…
Product Description:
- Model No.: 0021201
- Shell Color: White
- Channel/Button: 1
- Button Symbol: Call
- Operating Voltage: 6V(CR2032×2)
- Operating Current: 6mA±3mA
- Operating Frequency: 433.92Mhz
- Encoding Chip: EV1527
- Encoding Type: Learning code (up to 1 million codes, reducing code collision and unauthorized code scanning possibilities.)
- Transmitting Distance: 200m / 600ft (theoretically)
- The distance of 200m is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be exposed to some interference by other signals. Therefore, the actual distance may or may not reach 200m.
- Modulation Mode: ASK
- Operating Temperature: -20 ° C to +70 ° C
- Unit Size: 86mm x 86mm x 10mm
- Weight: 60g
- Case Material: Plastic
- This transmitter can work with different kinds of receivers, include
model 0020043 (S1U-DC12), 0020330 (S1U-AC220), 0020046 (S1PU-DC12), 0020275 (S1PU-AC220), 0020610 (S1RU-DC12), etc.
- Uses: garage doors, motorcycles, car alarm products, home security products, wireless remote control products, industrial control products.
Usage:
- Stick the remote button to wall or desk.
- When you press button, the receiver is activated, and the connected device is turned on.
- When you press button again, the receiver is deactivated, and the connected device is turned off.
Package Include:
- 1× Wireless Calling Button
- 2× CR2032 batteries
- 2× Double-sided adhesive tapes
Please Note:
1. The remote control and receiver will only work together if they have identical parameters, such as wireless frequency, encoding type, oscillation resistance, and operating channel.
2. Different remote controls are compatible with different receivers. If customers order only our remote controls, please confirm with us before placing the order to ensure they are compatible with the customer's receiver.
3. If customers order our remote controls separately without first confirming with us and subsequently discovers upon receipt that it is incompatible with their receiver, we will not assume any liability and will not accept returns or refunds.
