4 Buttons 50M EV1527 Coding Chip Wireless Remote Control / Transmitter

Manual

 Product Description:

 Model No.: 0021039 (XA-4L)
With Sliding Cover: Slide up when it doesn’t work (to protect the button). Slide down the button will appear.
Shell Color：Black
Channel/Button: 4
Button Symbol: A, B, C, D
Operating Voltage: 12V (1 x 27A -12V battery, can be used for 12 months)
Operating Current: 4mA
Operating Frequency: 433Mhz
Encoding Chip: EV1527
Encoding Type: Learning code (up to 1 million codes, reducing code collision and unauthorized code scanning possibilities.)
Transmitting Distance: 50m / 150ft (theoretically)
The distance of 50m is a theoretical data, it shall be operated in an open ground, no barriers, no any interference. But in the practice, it will be hindered by trees, walls or other constructions, and will be exposed to some interference by other signals. Therefore, the actual distance may or may not reach 50m.
Modulation Mode: ASK
Operating Temperature: -20 ° C to +70 ° C
Unit Size: 55mm x 32mm x 15mm
 Weight: 30g
Uses: garage doors, motorcycles, car alarm products, home security products, wireless remote control products, industrial control products

Please Note:
1. The remote control and receiver will only work together if they have identical parameters, such as wireless frequency, encoding type, oscillation resistance, and operating channel.
2. Different remote controls are compatible with different receivers. If customers order only our remote controls, please confirm with us before placing the order to ensure they are compatible with the customer's receiver.
3. If customers order our remote controls separately without first confirming with us and subsequently discovers upon receipt that it is incompatible with their receiver, we will not assume any liability and will not accept returns or refunds.
